當不銹鋼電纜橋架不方便或因空間條件有特殊要求時，可選用柔性連接板和鉸接板。彈性縫應設有彈性板；連接不同寬度和高度的托盤和梯子的兩個部件可以作為加寬板或替換板來配備。但在施工過程中，應根據規劃或工程布置條件選擇支、吊架和橋梁。

When stainless steel cable trays are inconvenient or have special requirements due to space conditions, flexible connection plates and hinged plates can be used. Elastic joints should be equipped with elastic plates; The two components that connect trays and ladders of different widths and heights can be equipped as widening plates or replacement plates. However, during the construction process, supports, hangers, and bridges should be selected according to the planning or engineering layout conditions.

一般用于敷設高度柔性的計算機電纜、通信電纜、熱電偶電纜等控制電纜。在腐蝕嚴重的環境下，對控制電纜起到良好的屏蔽和干擾作用，對電纜起到維護作用。

Generally used for laying highly flexible control cables such as computer cables, communication cables, thermocouple cables, etc. In environments with severe corrosion, it provides good shielding and interference for control cables, and serves as a maintenance tool for cables.

不銹鋼電纜橋架的寬度和高度由制造商根據以下要求選擇:電纜在橋架中的填充率，電力電纜不應大于40%；控制電纜不應大于50%。將來應該為額外的電纜預留一些備用空間；所選托盤和橋梁標準的承載能力應滿足要求。均勻載荷不應大于所選托盤和梯子載荷等級的額定均勻載荷。對于電纜橋架的設備，制造商選擇需要屏蔽電氣干擾的電纜線路。

The width and height of stainless steel cable trays shall be selected by the manufacturer according to the following requirements: the filling rate of cables in the tray shall not exceed 40% for power cables; Control cables should not exceed 50%. In the future, some spare space should be reserved for additional cables; The load-bearing capacity of the selected pallets and bridge standards should meet the requirements. The uniform load should not exceed the rated uniform load of the selected pallet and ladder load level. For cable tray equipment, manufacturers choose cable lines that need to be shielded from electrical interference.

有腐蝕性和易燃粉塵的地方應使用沒有蓋子和孔的封閉托盤。當電纜橋架需要根據當?shù)厍闆r調整方向時，應使用組裝好的托盤或帶孔和梯子的托盤?；覊m簡單堆積等需要隱藏的環境或室外場所應設置蓋板。當?shù)蛪弘娏€和控制線共用同一支架或梯形結構時，應選擇中間有隔板的支架或梯形結構。分支處應提供適當?shù)那郏雇斜P和梯架上下曲折；

Closed trays without covers and holes should be used in areas with corrosive and flammable dust. When cable trays need to be adjusted according to local conditions, assembled trays or trays with holes and ladders should be used. Cover plates should be installed in environments or outdoor areas that require concealment, such as simple accumulation of dust. When low-voltage power lines and control lines share the same bracket or trapezoidal structure, a bracket or trapezoidal structure with a partition in the middle should be selected. Appropriate twists and turns should be provided at the branch to allow the trays and ladders to twist up and down;

電纜橋架廠家在處理電纜橋架外觀工藝時，有必要更加關注電纜的分布環境。電纜分配環境的可用性豐富。有許多模型可以應用于許多不同的電氣環境。電纜橋架外形美觀，設備靈活，易于維護。因為使用量大，所以種類也不一樣。通過一些的技術，可以更好地保證輸電線路中橋梁。

It is necessary for cable tray manufacturers to pay more attention to the distribution environment of cables when dealing with the appearance process of cable trays. The availability of cable distribution environment is abundant. There are many models that can be applied to many different electrical environments. The cable tray has a beautiful appearance, flexible equipment, and is easy to maintain. Due to its high usage, the types are also different. Through some advanced technologies, bridges in transmission lines can be better ensured.
